Tricot Warp Knitting Machine with 3 Guide Bars
Automotive Fabrics Warp Knitting Machine HKS3M
Avadh Machinery Care offers high speed tricot machines hks3m and tricot warp knitting machine HKS4, which designed for producing elastic(lycra) warp knitted-fabrics and non-elastic textiles. The EL servo drive system makes the zig-zag patterns become available on the tricot warp knitting machines.
- Model: HKS3M
- Brand:Avadh Machinery Care
- Width: 186", 218", 245", 290", 330", 360"
- Gauge: E28, E32, E36
Product Description
- Tricot Machine HKS3M Overview
Avadh Machinery Careoffers 3 bars and 4 bars high-speed tricot machines, which are designed for producing elastic and non-elastic warp-knitted textiles.
Tricot Machine are equipped with compound needles also known as bearded needles. The sinker needles used in the tricot warp knitting machine control the fabric throughout the knitting cycle. The throats of the sinker needles hold the fabric while the tongue needles rise in order to form new loops.
Thanks to the EL servo drive system, the zig-zag patterns become available on the high-speed tricot warp knitting machines.
With more advanced functions applied, the tricot warp knitting machines are more durable and efficient. The working speed of HKS3M could reach 2,000 rpm, full bars and needle beds are made from high-strength carbon fiber material, and more flexible working widths are available: 186″, 218″, 245″, 290″, 330″, and 360″.
Tricot Machine HKS3M Fabrics Application:
HKS3M tricot machines mainly produce automotive interior textiles, sportswear, yoga wear, upholstery velvet fabrics, mesh nets, curtains, plush toys, and many other textiles. By 2021, the elastic crinkle fabrics made from HKS3M become widely popular in markets. Applications More+
- Product Description
| 1. Working Width/Gauge | 186″, 218″, 245″, 290″, 330″, 360″/E28, E32, E36; |
| 2. Working Speed | 50-2,000 rpm (Depends on Yarn and Designs); |
| 3. Bars/Knitting Elements | Individual Needle Bar with Compound Needles, Tongue Needles, 3 Guide Bars. All Bars and Beds are Made of Carbon-fiber-reinforced Material; |
| 4. Pattern Drive System | Pattern Discs Drive or EL Drive (Optional); |
| 5. Yarn Let-off Device | EBC Yarn Let-off System; |
| 6. Fabric Take-up | Electronical Fabric Take-up System; |
| 7. Batching Device | Electronical Batching Device; |
| 8. Laser Stop Detector, and Air-blower Device | Equipped. |
| 9. Heating Device | Equipped. |
| 10. Camera Detector | Optional. |
- Tricot Warp Knitting Machine HKS3M Features
1, Stable Working Performance;
2, Reliable Spare-parts Partners
(1) Needle Elements Suppliers: Groz-Beckert, Saxonia;
(2) EL Drives Suppliers: Mitsubishi, Nedic, Yasagawa;
(3) Bearing Suppliers: NSK, INA, FAG;
(4) Needle Beds and Bars Material: Magnalium Material;
(5) Electrical Elements Suppliers: Yaskawa, Mitsubishi, Schneider, Siemens, Omron, INVT;
(6) Take-up Belt: Bobotex.
3, Overseas Service Team: Turkey, India, Egypt, Indonesia, and Iran.
- Tricot Machine Spare Parts Quality
- Tricot Machine HKS3M Factory Installtion Images
1. do machine desgin and checking machine running action
2. inspection machine parts from oil tank production to machine bearing accembling process.
3. choose high quality machine parts
4. inspect evey step during machine assembling
5. in-house test before machine delivery
6. do solid package for exporting
- Tricot Machine HKS3M Running Vedios
- Avadh Machinery Care Services & Why choose us
- Services
The local service team in Turkey, Egypt, India, Pakistan, Indonesia
In-time online service
Detailed operation manual
Machine in-house test before delivery
- Why choose Avadh Machinery Caretextile
OEM&ODM: 15+ years experience in warp knitting machineproduction, can provide OEM&ODEM
TECHNICAL TEAM: Stability project Experienced R&D technicalteam, strict QC control, so that the machineprecision is higher, more stable operation
RICH IN EXPERIENCE: Experienced international commissioningteam with commissioning experience inseveral countries
REMOTE SUPPORT: The equipment is equipped with remote servicesystem to provide timely technical support forglobal customers more efficiently!
ONE-STOP SERVICE: To provide customers with one-stop service,including equipment, technical solutions, spareparts and post-processing technical consuitation.
DESIGN SHARING: Share the latest market fabric design withcustomers
- Company Information
CHANGZHOU Avadh Machinery Care. is a warp knitting machines and spare parts manufacturer, which locates in Changzhou, China. In the past 15 years, we have already provided nearly 1,000 sets of warp knitting machinery in markets, including Multi-bar Raschel machines, Jacquard Machines, Tricot Machines, Double-Needle Bars Machines, and Warping Machines.
Driven by a responsible attitude, ongoing innovation, and open collaboration, Avadh Machinery Carehas established a competitive warp knitting technology (WKT) portfolio of end-to-end solutions in warp knitting machinery, spare parts, and technology training, and the markets including China, Turkey, India, Egypt, Indonesia, Bangladesh, Brazil, Pakistan, Syria, Iran, Kenya, Thailand, Mexico, and other countries and areas.
Thanks to the sound technology and in-time after-sales service, Avadh Machinery Carehas won a high reputation from markets, and Avadh Machinery Careis committed to enabling the warp knitting future diversified industry and building a better world.
Manufacturing Factories:
We have four workshops, two of them are warp knitting machines and warping machines workshops, another two are fabric production mill and spare parts manufacture workshop separately.
Most of our newly developed machines will be used in our fabric knitting factory for a profound test, after which, we will promote into the market.
Spare parts such as compound needle bed, tongue needle bed, needle guide bar, sinker bed, and latch needle bed are produced in our CNC machines, the bars or beds used on Chinese and German warp knitting machines.
Manufacturing Factories:
We attend professional textile machinery exhibitions worldwide, such as ITMA, ITM, ITME, and many others. During the exhibition, we not only display our newly developed technology but also offer economical products to our customers.
It is also a good time to collect customers' feedback and new demand so that we could make better machines for them.
Communication and Cooperation are our themes and participated in all exhibitions.
Customer Training:
Technical support plays an extremely role in warp knitting machine services. We offer different forms of training, including professional manual books, online guides, video albums, and on-site training.
So far, we have offered on-site training in more than 10 countries and built up our local service teams in Turkey, India, Pakistan, Indonesia, Iran, and Egypt.
Our in-time & professional technical support gain a high reputation in markets.
- FAQ
Avadh Machinery Care is established as a trading company to serve customers with machines, spare parts, and yarn for the international markets. But we have had our own production plant for over 10 years. We are not simply an installation factory, since we have our own professional R&D team.
From the technical team, our technical team has been in this field for more than 20 years. They know machine structures, machine parts qualities, and machines skills very well.
We have our own CNC plant. For most machine parts, we have stable suppliers but we will still do CNC work to reduce the size difference before machine installation to improve our machine stability and make them more durable.
For after-sale service, our sales and technical team are always online for our customers. When they need our technical support, we always provide in-time service. Meanwhile, we have local service team in some markets.
